CT20

Smart Countertop POS Terminal

The NEXGO CT20 is a versatile, powerful smart payment terminal designed for countertop use, complete with an optional desktop stand. Built on Android 11 with a 2.0GHz quad-core processor, it delivers reliable, secure payment processing and integrates seamlessly with ECRs and external devices.

Ideal for retail, hospitality, grocery and service desk environments, the CT20 combines multiple connection interfaces, a physical keypad with optional privacy shield, and a built-in thermal printer in one user-friendly countertop device.

Key Features

4.0″ 480 x 800 IPS LCD capacitive touchscreen
Android 11 with quad-core Cortex-A53 2.0GHz processor
2GB DDR RAM + 8GB Flash memory
Multiple interfaces: RS232, LAN, USB Type-A, USB Type-C
15-key physical keypad with optional removable privacy shield
Built-in high-speed thermal printer (58mm)
Optional 4G/3G/2G with Wi-Fi 5 (2.4G/5G) and BT5.X
PCI 6.x and EMV L1 / CL1 certified

Specifications

Android 11
Quad-Core Cortex A53 2.0GHz Processor
4.0″ 480 x 800 IPS LCD Capacitive Touchscreen
15 Physical Keys with Optional Privacy Shield
PCI 6.x, EMV L1, EMV CL1 Certified

Smart Countertop Power, Simple to Deploy

Designed to slot into modern checkout environments while delivering all the connectivity, security and print capability merchants need at the counter.

Multi-Interface Ready: RS232, LAN, USB Type-A and Type-C for seamless ECR and peripheral integration.
Built-In Printing: High-speed thermal printer keeps receipts flowing.
Physical Keypad: 15 keys with removable privacy shield for secure PIN entry.
Flexible Connectivity: LAN, Wi-Fi 5 and optional 4G/3G/2G.

Multiple Payment Methods

Flexible Connectivity

Integrate seamlessly into your existing infrastructure.

Secure & Compliant

Protect your business and customers with advanced security.

Rugged & Reliable

Built to withstand tough environments and 24/7 use.

Customer Engagement

Enhance the payment experience and drive loyalty.

Technical Specifications

Electrical

BASED ON ANDROID 11

Processor

QUAD-CORE CORTEX A53, 2.0GHZ

Memory

2GB RAM + 8GB ROM

Adaptor

DC 9V / 2A

Communication

LAN; WI-FI 802.11A/B/G/N/AC 2.4GHZ & 5GHZ; BT5.X; 4G/3G/2G (OPTIONAL)

Certifications

PCI 6.X, EMV L1, EMV CL1, QUICKPASS, PAYPASS, PAYWAVE, TQM, JCB, DISCOVER, AMEX, FCC, CE, ROHS

Environmental

Operating Temperature

-10°C TO 45°C

Storage Temperature

-20°C TO 70°C

Relative Humidity

10% TO 95% (NON-CONDENSING)

Mechanical

Dimensions

186 X 82 X 72 MM

Display

4.0" 480 X 800 IPS LCD CAPACITIVE TOUCHSCREEN

Keypad

15 PHYSICAL KEYS (NUMERIC / FUNCTION); REMOVABLE PRIVACY SHIELD OPTIONAL

Ports

1 X USB TYPE-A, 1 X USB TYPE-C, 1 X LAN, 2 X RS232

Printer

HIGH SPEED THERMAL PRINTER, 58MM WIDTH, 40MM DIAMETER
